Hovall 54 Watt 12 Volt Monocrystalline Flexible Solar Panel
Wanna the best solar panel cost? this is your best choice -Hovall 54W 12V Mono-crystalline Flexible Solar Panel.
Features:
- Smart and environment protection.
- Corrosion Resistance.
- Fast Charging, this Hovall solar panel delivers the high power output and fast charging capacity.
- High transformation efficiency, the Monocrystalline silicon efficiency can up to 20 percent.
- Lightweight and thin, so it is easy to use, carry, hang and install.
- Use this unit attach to fit any curved surface for Boat, RV, Sleeper Cab, and any other mobile unit’s battery.
- The junction box with diodes, safety protection.
- The Charging temperature is -20 – 70-degree centigrade.
- Flexible Solar Panel, A maximum 30 degree arc bendable.
- Short Circuit and surge protection technology keep you and your devices safe.
- Durable design, water-resistant and long lifespan.
- CE, RoHS and FCC certificates.
- Can be customized.
Specifications:
Typical Electrical Data | At STC: 25℃, 1000 W/m2 and AM 1.5 |
---|---|
Model: HT-SP-M1205000AA | Short-Circuit Current (Isc): 3.3A |
Maximum Power (Pmax): 54 W | Power Tolerance: ±3% |
Optimum Working Voltage (Vmp): 18 V | Maximum System Voltage: 600 VDC |
Optimum Working Current (Imp): 3 A | Maximum Series Fuse Rating: 15 A |
Open-Circuit Voltage (Voc): 21.5 V | |
Mechanical Data | |
Solar Cell Type: Monocrystalline | Connectors: MC4 Connectors |
Number of Cells: 36 pcs (4 x 9) | Junction Box: IP67 |
Panel Dimensions: 620 x 540 x 3mm | Weight: 0.98 KG |
Thermal Characteristics | |
Temperature Coefficient of Pmax: -0.42%/℃ | Operating Module Temperature: -40℃ to +90℃ |
Temperature Coefficient of Voc: -66.2 mV/℃ | Nominal Operating Cell Temperature (NOCT): 45±2℃ |
Temperature Coefficient of Isc: 2.0mA /℃ | |
MC4 Connectors | |
Rated Current: 30 A | Temperature Range: -40ºF to 194ºF |
Maximum Voltage: 1000 VDC | IP Rating: IP 67 |
Junction Box | |
IP Rating: IP68 | Output Cables: 2.5 mm2 (90cm long) |
Number of Diodes: 1 Diode(s) | |
Module Diagram | IV-Curve |
